Vivax - DT AERI - DUCT SPLIT SYSTEM
STATIC PRESSURE - Maximum static pressure is 160 Pa.
BUILT-IN CONDENSATE DRAIN PUMP - The drain pump raises condensate up to 1.000 mm.
A++ Cooling SEER 6.5
A+ Heating SCOP 4.0
Version
Model - DT AERI ACP-12DT35AERI+ R32
Capacity(W) - Cooling: 3520 (530~3990) / Heating: 3810 (1000~4390)
Cooling operating range - -15 °C ≤ T ≤ 50 °C
Heating operating range - -20 °C ≤ T ≤ 24 °C
Noise - Sound Pressure (dB(A)) - HI / MID / LOW / SI - 34.5 / 30.5 / 29 / 23 (indoor unit)
Noise - Sound Pressure (dB(A)) - ≤ 55.5 (outdoor unit)
Packaging dimensions (mm) 860 x 540 x 285 (indoor unit) / 887 x 337 x 610(outdoor unit)
Device dimensions (mm) 700 x 506 x 200 (indoor unit) / 765 x 303 x 555(outdoor unit)
Power input (W) - Cooling: 1053 (155~1373) / Heating: 1053 (155~1373)
Power Supply - ~220-240V/1/50Hz; Indoor and outdoor unit
Model - DT AERI ACP-18DT50AERI+ R32
Capacity(W) - Cooling: 5280 (2550~5860) / Heating: 5570 (2200~6150)
Cooling operating range - -15 °C ≤ T ≤ 50 °C
Heating operating range - -20 °C ≤ T ≤ 24 °C
Noise - Sound Pressure (dB(A)) - HI / MID / LOW / SI - 41 / 38 / 34 / 26 (indoor unit)
Noise - Sound Pressure (dB(A)) - ≤ 55 (outdoor unit)
Packaging dimensions (mm) 1070 x 725 x 280(indoor unit) / 915 x 370 x 615 (outdoor unit)
Device dimensions (mm) 880 x 674 x 210 (indoor unit) / 805 x 330 x 554 (outdoor unit)
Power input (W) - Cooling: 1530 (710~2150) / Heating: 1510 (740~1760)
Power Supply - ~220-240V/1/50Hz; Indoor and outdoor unit
Model - DT AERI ACP-24DT70AERI+ R32
Capacity(W) - Cooling: 7030 (3280~8160) / Heating: 7620 (2810~8490)
Cooling operating range - -15 °C ≤ T ≤ 50 °C
Heating operating range - -20 °C ≤ T ≤ 24 °C
Noise - Sound Pressure (dB(A)) - HI / MID / LOW / SI - 42 / 40 / 37 / 27 (indoor unit)
Noise - Sound Pressure (dB(A)) - ≤ 62 (outdoor unit)
Packaging dimensions (mm) 1305 x 805 x 315 (indoor unit) / 995 x398 x 740 (outdoor unit)
Device dimensions (mm) 1100 x 774 x 249 (indoor unit) / 890 x 342 x 673 (outdoor unit)
Power input (W) - Cooling: 2190 (750~2960) / Heating: 1900 (640~2580)
Power Supply - ~220-240V/1/50Hz; Indoor and outdoor unit
Model - DT AERI ACP-36DT105AERI+ R32
Capacity(W) - Cooling: 10550 (2730~11780) / Heating: 11720 (2780~12840)
Cooling operating range - -15 °C ≤ T ≤ 50 °C
Heating operating range - -20 °C ≤ T ≤ 24 °C
Noise - Sound Pressure (dB(A)) - HI / MID / LOW / SI - 49.5 / 48 / 46 / 42.5 (indoor unit)
Noise - Sound Pressure (dB(A)) - ≤ 65 (outdoor unit)
Packaging dimensions (mm) 1570 x 805 x 330 (indoor unit) / 1090 x 500 x 885 (outdoor unit)
Device dimensions (mm) 1360 x 774 x 249 (indoor unit) / 946 x 410 x 810 (outdoor unit)
Power input (W) - Cooling: 4000 (890~4200) / Heating: 3250 (780~4000)
Power Supply - ~220-240V/1/50Hz IU, ~380-415V/3/50Hz OU
Model - DT AERI ACP-48DT140AERI+ R32
Capacity(W) - Cooling: 14070 (3520~15530) / Heating: 16120 (4100~18170)
Cooling operating range - -15 °C ≤ T ≤ 50 °C
Heating operating range - -20 °C ≤ T ≤ 24 °C
Noise - Sound Pressure (dB(A)) - HI / MID / LOW / SI - 50 / 49 / 47 / 42 (indoor unit)
Noise - Sound Pressure (dB(A)) - ≤ 66 (outdoor unit)
Packaging dimensions (mm) 1405 x 915 x 365 (indoor unit) / 1095 x 495 x 1480 (outdoor unit)
Device dimensions (mm) 1200 x 874 x 300 (indoor unit) / 952 x 415 x 1333 (outdoor unit)
Power input (W) - Cooling: 4800 (880~6000) / Heating: 4500 (950~5700)
Power Supply - ~220-240V/1/50Hz IU, ~380-415V/3/50Hz OU
Model - DT AERI ACP-55DT160AERI+ R32
Capacity(W) - Cooling: 15240 (4100~17290) / Heating: 18170 (4400~20520)
Cooling operating range - -15 °C ≤ T ≤ 50 °C
Heating operating range - -20 °C ≤ T ≤ 24 °C
Noise - Sound Pressure (dB(A)) - HI / MID / LOW / SI - 52.5 / 51 / 49 / 47 (indoor unit)
Noise - Sound Pressure (dB(A)) - ≤ 66(outdoor unit)
Packaging dimensions (mm) 1405 x 915 x 365 (indoor unit) / 1095 x 495 x 1480 (outdoor unit)
Device dimensions (mm) 1200 x 874 x 300 (indoor unit) / 952 x 415 x 1333 (outdoor unit)
Power input (W) - Cooling: 5250 (1030~6650) / Heating: 5150 (950~6600)
Power Supply - ~220-240V/1/50Hz IU, ~380-415V/3/50Hz OU
